Validator SOP Part 1: Hardware, Software, & Deposit Setup

Step 0 Purchase Equipment and Assemble NUC

First, you’ll need hardware to run the validator software on. Requirements can be found here, suggested hardware are as follows:

Intel NUC 11+ (tall) - bare-bones model with 6+ core CPU
16GB RAM (32GB preferred) - ‘laptop’ RAM (not full size)
M.2 SSD 2TB (4TB preferred)
Ethernet connection with 300 Mbps symmetrical
USB drive (used to install Linux) 4GB+
HDMI (or USB) cord and connectable monitor for initial set up
USB keyboard and mouse (mouse is only required if using Ubuntu desktop to generate new validator keys)

While not a hard requirement, it’s also recommended to purchase a 1000+VA sine wave UPS to act as a battery backup in the case of a power failure. Note that in order for this to be effective, you should plug the validator and internet infrastructure into the UPS. The goal is to guard against both unclean shutdowns as well as downtime.

Once equipment has been obtained, simply install the RAM and SSD in the NUC. Because some of the below processes require using an air-gapped machine, do not connect the device to the internet.

Note: You will also need a small screwdriver to handle installation.

An example hardware list can be found here.

Step 1 Generate Staking Data

Only if setting up a new validator:

If setting up a new validator (and haven’t already generated deposit data and validator key(s)), you’ll need to run the deposit tool CLI, and should do so from an air-gapped machine.

If you are not generating new keys, skip to step 2.

If you are adding new validators to an existing config, please see the Addendum at the bottom of this document

In order to have a machine ready to go, we will need to install an OS on your new validator hardware built in step 0. We’ll be using Ubuntu Desktop. On your laptop, navigate to ubuntu.com, download the latest LTS copy of Ubuntu Desktop (as of 12.15.23, 22.04.3 LTS). In addition, download and install the Etcher tool which will allow you to flash the operating system onto the USB drive. Lastly, download the latest version of the deposit CLI tool - you want the AMD64 version (as of 12.15.23, 2.7.0), and unzip the executable file.

With all the software and data assembled, run the Etcher tool to flash the USB drive with Ubuntu Desktop using your laptop. Insert the USB into your air gapped machine (built in step 0), connect the machine to a monitor via HDMI (or USB), keyboard, and mouse, and go through the installation process (which should occur automatically). Make sure to choose the minimum settings allowed so things go quickly.

Once the installation is complete, remove the USB drive, and reformat the disk to exFAT so you can move the deposit CLI tool onto the USB drive. You may also want to drop a text file into the USB drive with your withdrawal address to make the next step easier.

Note: If you plan to set up your validator and take advantage of restaking via EigenLayer, you will likely want to check this portion of the guide as you can avoid exiting and re-entering by setting up the wihdrawal address correctly during this step.

Finally, re-insert the USB drive into the NUC and move the deposit CLI tool to your desktop.

Now, run the binary file in a terminal window on your Linux desktop by using the below command (easier if you have your withdrawal address handy for a copy/paste!)

sudo ./deposit new-mnemonic --num_validators {#_Validators} --chain mainnet --eth1_withdrawal_address {YourWithdrawalAddress}

Replace {#_Validators} with the number of validators you want to run (32ETH per), and {YourWithdrawalAddress} with an Ethereum address you control.

NOTE: Once set, the withdrawal address CANNOT be changed, so be ABSOLUTELY SURE that it is an address you control the private keys for (or it’s a multisig and you control the private keys to the underlying wallets) and correctly specified. For example: —eth1_withdrawal_address 0xd8dA6BF26964aF9D7eEd9e03E53415D37aA96045

DO NOT set the withdrawal address to a central exchange wallet or account. This MUST be an EOA or smart contract wallet, as ETH is not “transferred” but rather “generated” in the wallet via a state change, and that doesn’t play nicely with Coinbase/Kraken/etc.

Once you execute the above steps, confirm your withdrawal address within the generated files, and provide your language preferences. You will then be asked to create the validator keystore password. Note this password on the variables document. You will need this later to import the validator(s) into the Consensus Client. Please note that this document will be referenced a number of times below, and is meant to serve as an example for a way to keep a secure paper record of your passwords, file locations, etc.

Next, a seed phrase (mnemonic) will be generated. Back it up somewhere safe. This is CRITICAL. You will need this to add additional validators or to regenerate keys if lost. IF YOU LOSE THIS MNEMONIC, YOU MAY LOSE ACCESS TO THE VALIDATOR! Not your keys, not your coins.

Once you have confirmed your mnemonic your validator(s) will be created. The following files will be generated and placed on your desktop.

The deposit_data-[timestamp].json file contains the public key(s) for the validator(s) and information about the staking deposit. This file will be used to complete the ETH staking deposit process later in this guide. This is where you can triple check the withdrawal address
The keystore-[..].json files contain the encrypted validator signing key. There is one keystore file per validator that you are funding. These will be imported into the Consensus Client for use during validation operations.
If you lose or accidentally delete the files it is possible to regenerate them using the Staking Deposit CLI tool and your mnemonic via the existing-mnemonic command (see here).

Now that you have generated the deposit data, keystore file(s), validator password, and the mnemonic, we can begin setting up the node. You should now copy the generated deposit and keystore files back onto your USB drive. We’ll need them later on.

Note: there are no other steps in this process that require you to enter or view your mnemonic phrase, so the air-gapped portion of this process is completed. You can now plug in the Ethernet cord.

Step 2 Install Linux Server

Navigate to ubuntu.com, download the latest LTS copy of Ubuntu Server (as of 12.15.23, 22.04.3 LTS). In addition, download and install the Etcher tool which will allow you to flash the operating system onto the USB drive. Then, run the Etcher tool to flash the USB drive with Ubuntu Server.

Once that’s complete, pop the USB drive into your NUC, and restart it - also connect it to Ethernet if you haven’t already. Upon restart, hold fn+F10 in order to boot from USB. Follow the installation instructions, making sure to select the following settings:

When setting up hard drive settings, uncheck the LVM box else the full HD cannot be used
You should make sure no software is downloaded or installed aside from OpenSSH
Do not select “minimum” when installing the software, you will need the items downloaded and installed in the normal process
Name your device whatever you like - and note this on your variable document
Create a user when prompted to do so, and set a password for that user that’s sufficiently complex - note this on your variable document

Once this process is complete, you should be presented with a terminal window on screen. Likely, you will need to enter your password to gain access to the server.

Next, update the server by running the following commands:

sudo apt -y update && sudo apt -y upgrade && sudo apt dist-upgrade && sudo apt autoremove
sudo reboot

After rebooting:

df -h

That last command is used to ensure that the expected amount of free space on your SSD is available. If this value is less than 75% of the full size of the drive, something went wrong (likely the LVM checkbox during Linux installation), and you’ll need to start this step over.

Step 3 Secure the Server

After the updates and restart complete, it’s time to change some security settings.

Modify the Default SSH Port

Port 22 is the default SSH port and a common attack vector. Change the SSH port to avoid this.

Choose a port number between 1024–49151 and run the following command to check is not already in use:

sudo ss -tulpn | grep ':{YourSSHPortNumber}'

A blank response indicates not in use, a red text response indicates it is in use: try a different port.

If confirmed available, modify the default SSH port number by updating your server’s SSH config. Open the config file with the following command:

sudo nano /etc/ssh/sshd_config

Find the line Port 22 in the file. Remove the # and change the value to your chosen port. Note this port number on the variables document as you’ll need it for LAN access (we’re almost ready to do the rest from your laptop!)

Press CTRL + X then Y then ENTER to save and exit.

Restart the SSH service to reflect the changes.

sudo systemctl restart ssh

Configure the Firewall

Install UFW:

sudo apt install ufw

Next, apply UFW defaults:

sudo ufw default deny incoming && sudo ufw default allow outgoing

Next, we’ll need to create some custom rules to allow the requisite network activity/connections

Allow Custom SSH Port:

sudo ufw allow {YourSSHPortNumber}/tcp

Deny Default SSH Port:

sudo ufw deny 22/tcp

Allow Execution Client Port 30303:

sudo ufw allow 30303

Note that if the —port and —discovery.port flags are used in the Geth configuration file in step 7, you will need to ensure the ports used are allowed as described above.

Allow Prysm:

sudo ufw allow 13000/tcp && sudo ufw allow 12000/udp

With settings imported, enable the firewall by running:

sudo ufw enable

Then run the following command to see a list of ports enabled/disabled:

sudo ufw status numbered

Finally, run the following command to get your local IP:

hostname -I

Note this on your variables document.

WITHOUT disconnecting from the Node, head over to your laptop (or whichever LAN device you plan on accessing the Node from), and attempt to connect. Open a terminal window and input the following command to edit your hosts file so you can refer to the Node by the name you set it as in addition to its IP:

sudo nano /etc/hosts

When prompted, enter your password. Now, above the final ::1 localhost line, create a new line, and add the local IP of your node (see: variables), then a few spaces so you’re aligned with the localhost text, and then enter the name of the Node you used above (see: variables).

Now, lets test to see if you can SSH into your Node. Simply open a new terminal window, and enter the following command, subbing in the name of the Node, user, and the SSH port (see: variables).

ssh {yourusername}@{node_name OR node_IP} -p {YourSSHPortNumber}

Enter your password when prompted. If you are able to log in and see {user}@{node_name}, you’re set! Once you see this, you can disconnect the Node from the monitor and keyboard, and can preform the remainder of tasks from any laptop or computer on the same LAN using the command above to SSH in. The Node only needs to remain connected to power and ethernet (powered via UPS if possible).

Configure Fail2Ban

Fail2Ban is an intrusion-prevention program that scans log files and and bans IPs that show malicious activity. If a certain number of failed logins are detected from a specific IP address (within a specified amount of time), that IP address is blocked. This service provides basic protection against brute-force attacks, and can be configured to ignore local IPs.

Install fail2ban, and enable and start the service:

sudo apt install -y fail2ban && sudo systemctl enable fail2ban

Create the configuration file for the service:

sudo nano /etc/fail2ban/jail.local

Then, paste the following configuration into the file:

[sshd]
enabled = true
port = {your SSH port}
filter = sshd
logpath = /var/log/auth.log
maxretry = 4
# whitelisted IP addresses
ignoreip = 192.168.1.0/24 127.0.0.1/8

NOTE: The inclusion of ignoreip = 192.168.1.0/24 127.0.0.1/8 is to allow local IPs to connect (and potentially get passwords wrong) without being blocked.

Press CTRL + X then Y then ENTER to save and exit.

Reload systemd to reflect the changes and start the service. Check the status to make sure it’s running correctly:

sudo systemctl daemon-reload
sudo systemctl start fail2ban
sudo systemctl status fail2ban

If it says “active (running)” in green text, you’ve done it! Press Q to quit (this will not effect the fail2ban service)

Disable Root Access

It is best practice to not log in as root in order to maintain security and follow the principle of least-privilege.

First, check to ensure another user besides root can run the sudo command (if you’ve gotten this far, this is just a double check step). Let’s first check sudo access:

sudo -l

If you see the text “User {your-username} may run the following commands on {device-name}: (ALL:ALL) ALL” you have sudo privileges with your current user.

Now, lock the root account:

sudo passwd -l root

You should see the text “passwd: password expiry information changed.”

If for any reason you need to unlock the root account:

sudo passwd -u root

Step 4 Configure Port Forwarding

From your laptop (or whichever device on the local network you plan on accessing the Node from), log into your router to edit the port forwarding settings. While access is different for each network set up and router, usually you can access your router at 192.168.1.1 or a similar local IP address. Occasionally, instructions can be found on the router itself.

Once you’ve logged in to your router, edit the port forwarding settings for your Node such that port 30303 is forwarded to port 30303 for both UDP and TCP protocols.

This is the same port we allowed above in the Secure the Server step - port forwarding 30303 will make it easier for the execution client (Geth) to find suitable peers. Failure to do some may result in sub optimal syncing.

If the —port and —discovery.port flags are used in the Geth configuration file in step 7, you will need to ensure the ports used are forwarded as described above.

Step 5 Configure Timekeeping

Running validators against a blockchain requires accurate timekeeping in order to ensure proper synchronization with the network. Ubuntu has time synchronization built in and activated by default using timedatectl.

Verify this system is running:

timedatectl

In the returning dialogue, it should show NTP service: active. If for some reason it is not, run the following command:

sudo timedatectl set-ntp on

Step 6 Generate Client Auth Secret

On the server, communication between the Execution and Consensus clients is secured using a JSON Web Token (JWT) authentication scheme. The JWT is represented by a file that contains a randomly generated 32-byte hex string. The Execution and Consensus clients each make use of the file for message authentication.

First, create a directory to store this file:

sudo mkdir -p /var/lib/jwtsecret

Then, generate the JWT file using openssl:

openssl rand -hex 32 | sudo tee /var/lib/jwtsecret/jwt.hex > /dev/null

Finally, check that the file was created as expected:

sudo nano /var/lib/jwtsecret/jwt.hex

Press CTRL+X to exit

Step 7 Install Geth

Time to install Geth! All commands provided below are based on the 1.14.5 version of Geth (current as of 6.7.24), but should be adjusted based on whatever the latest version of Geth is here - simply right click and copy the URL on the ‘FOR LINUX’ box. Note that MANY commands below will need to update if this version is updated.

Curl the Geth build from the above link:

cd ~
curl -LO https://gethstore.blob.core.windows.net/builds/geth-linux-amd64-1.14.5-0dd173a7.tar.gz

Extract the files from the archive and copy to the /usr/local/bin directory. The Geth service will run it from there. Modify the file name to match the downloaded version:

tar xvf geth-linux-amd64-1.14.5-0dd173a7.tar.gz
cd geth-linux-amd64-1.14.5-0dd173a7
sudo cp geth /usr/local/bin

Clean up the files. Modify the file name to match the downloaded version:

cd ~
rm geth-linux-amd64-1.14.5-0dd173a7.tar.gz
rm -r geth-linux-amd64-1.14.5-0dd173a7

Geth will be configured to run as a background service. Create an account for the service to run under. This type of account can’t log into the server:

sudo useradd --no-create-home --shell /bin/false geth

Create the data directory. This is required for storing the Ethereum blockchain data:

sudo mkdir -p /var/lib/geth

Set directory permissions. The Geth user account needs permission to modify the data directory:

sudo chown -R geth:geth /var/lib/geth

Create a systemd service config file to configure the service:

sudo nano /etc/systemd/system/geth.service

Then, paste the following configuration into the file:

[Unit]
Description=geth Execution Client (Mainnet)
After=network.target
Wants=network.target
[Service]
User=geth
Group=geth
Type=simple
Restart=always
RestartSec=5
TimeoutStopSec=600
ExecStart=/usr/local/bin/geth \
  --mainnet \
  --datadir /var/lib/geth \
  --authrpc.jwtsecret /var/lib/jwtsecret/jwt.hex \
  --db.engine pebble
[Install]
WantedBy=default.target

NOTE: The inclusion of TimeoutStopSec=600 is to allow the Geth service sufficient time to write cached data to disk on clean shutdown.

Press CTRL + X then Y then ENTER to save and exit.

Reload systemd to reflect the changes and start the service. Check the status to make sure it’s running correctly:

sudo systemctl daemon-reload
sudo systemctl start geth
sudo systemctl status geth

If it says “active (running)” in green text, you’ve done it! Press Q to quit (this will not effect the Geth service)

The sync will begin immediately. Use the journal output to follow the progress or check for errors by running the following command.

sudo apt install ccze
sudo journalctl -fu geth | ccze

Press CTRL+ C to exit (will not affect the Geth service).

Next, enable the Geth service to automatically start on reboot:

sudo systemctl enable geth

Finally, stop and start geth so it’s using all the latest config information:

sudo systemctl stop geth
sudo systemctl start geth

Now that Geth is all set up, you can run the Geth attach command, and check things like sync status as well as connected peers.

First, attach the Geth console:

sudo geth attach /var/lib/geth/geth.ipc

Now, you can check the sync status, but this won’t be working until after we install Prysm (see steps 7-9):

eth.syncing

You can also check the count of connected peers by running:

net.peerCount

After running Geth for ~10 or so minutes, check the peer count to ensure it’s greater than 0.

Step 8 Install Prysm

The Prysm Consensus Client is made up of two binaries that provide the functionality of the beacon node and validator, respectively. This step will download and prepare the Prysm binaries.

Time to install Prysm! All commands provided below are based on the 5.0.4 version of Prysm (current as of 6.20.24), but should be adjusted based on whatever the latest version of Prysm is here. Note that many commands below will need to update if this version is updated.

In the Assets section (expand if necessary) copy the download links to the beacon-chain-v…-linux-amd64 file and the validator-v…-linux-amd64 file. Be sure to copy the correct links. Download the binaries using the commands below. Modify the URL to match the copied download links:

cd ~
curl -LO https://github.com/prysmaticlabs/prysm/releases/download/v5.0.4/beacon-chain-v5.0.4-linux-amd64
curl -LO https://github.com/prysmaticlabs/prysm/releases/download/v5.0.4/validator-v5.0.4-linux-amd64

Now, let’s rename the files and make them executable and copy them to the /usr/local/bin directory. The Prysm services will run them from there. Modify the file names to match the downloaded version:

mv beacon-chain-v5.0.4-linux-amd64 beacon-chain
mv validator-v5.0.4-linux-amd64 validator

chmod +x beacon-chain
chmod +x validator

sudo cp beacon-chain /usr/local/bin
sudo cp validator /usr/local/bin

Finally, clean up the files

rm beacon-chain && rm validator

Step 9 Configure the Beacon Node Service

Set up an account for the services to run under (note: this type of account cannot log into the server):

sudo useradd --no-create-home --shell /bin/false prysmbeacon

Next, set up the directories and permissions for prysmbeacon:

sudo mkdir -p /var/lib/prysm/beacon
sudo chown -R prysmbeacon:prysmbeacon /var/lib/prysm/beacon

Next, create and configure the service file:

sudo nano /etc/systemd/system/prysmbeacon.service

And then paste the following data into the file:

[Unit]
Description=Prysm Consensus Client BN (Mainnet)
Wants=network-online.target
After=network-online.target
[Service]
User=prysmbeacon
Group=prysmbeacon
Type=simple
Restart=always
RestartSec=5
ExecStart=/usr/local/bin/beacon-chain \
  --mainnet \
  --datadir=/var/lib/prysm/beacon \
  --execution-endpoint=http://127.0.0.1:8551 \
  --jwt-secret=/var/lib/jwtsecret/jwt.hex \
  --suggested-fee-recipient={FeeRecipientAddress} \
  --checkpoint-sync-url={CheckpointSyncURL} \
  --genesis-beacon-api-url={CheckpointSyncURL} \
  --accept-terms-of-use
Environment=USE_PRYSM_MODERN=true
[Install]
WantedBy=multi-user.target

Make sure to replace {FeeRecipientAddress} with the address you’d like to receive the validator tip fees.

Make sure to replace {CheckpointSyncURL} (x2) with a valid checkpoint sync URL see here for more information - be sure to select a Mainnet endpoint.

Press CTRL + X then Y then ENTER to save and exit.

Reload systemd to reflect the changes and start the service. Check the status to make sure it’s running correctly:

sudo systemctl daemon-reload
sudo systemctl start prysmbeacon
sudo systemctl status prysmbeacon

If it says “active (running)” in green text, you’ve done it! Press Q to quit (this will not effect the PrysmBeacon service) - the sync has already begun.

Use the journal output to follow the progress or check for errors by running the following command:

sudo journalctl -fu prysmbeacon | ccze

Finally, enable the service to automatically start on reboot:

sudo systemctl enable prysmbeacon

Step 10 Configure the Validator Service

Set up an account for the services to run under (note: this type of account cannot log into the server):

sudo useradd --no-create-home --shell /bin/false prysmvalidator

Create a directory to store the validator data:

sudo mkdir -p /var/lib/prysm/validator

Next, set up the directories and permissions for prysmbeacon:

sudo chown -R prysmvalidator:prysmvalidator /var/lib/prysm/validator

Next, create and configure the service file by running:

sudo nano /etc/systemd/system/prysmvalidator.service

And then paste the following data into the file:

[Unit]
Description=Prysm Consensus Client VC (Mainnet)
Wants=network-online.target
After=network-online.target
[Service]
User=prysmvalidator
Group=prysmvalidator
Type=simple
Restart=always
RestartSec=5
ExecStart=/usr/local/bin/validator \
  --datadir=/var/lib/prysm/validator \
  --wallet-dir=/var/lib/prysm/validator \
  --wallet-password-file=/var/lib/prysm/validator/password.txt \
  --suggested-fee-recipient={FeeRecipientAddress} \
  --graffiti="{yourgraffiti}" \
  --accept-terms-of-use
[Install]
WantedBy=multi-user.target

Make sure to replace {FeeRecipientAddress} with the address you’d like to receive the validator tip fees.

Make sure to replace {yourgraffiti} with your own graffiti string (max 32 bytes). (e.g. —graffiti=“Endaoment.org”)

Press CTRL + X then Y then ENTER to save and exit.

Note that you can check the byte count by running a simple python command from terminal on your laptop:

python3
>> len("{yourgraffiti}".encode())

If the result is 32 or less, you’re in the clear.

Reload systemd to reflect the changes and start the service. Check the status to make sure it’s running correctly:

sudo systemctl daemon-reload
sudo systemctl start prysmvalidator
sudo systemctl status prysmvalidator

If it says “active (running)” in green text, you’ve done it! Press Q to quit (this will not effect the PrysmValidator service) - the sync has already begun.

Use the journal output to follow the progress or check for errors by running the following command:

sudo journalctl -fu prysmvalidator  | ccze

Finally, enable the service to automatically start on reboot:

sudo systemctl enable prysmvalidator

Now that the beacon-chain, validator, and execution client software is all set up, you should run the following Geth attach commands to check sync status:

First, attach the Geth console:

sudo geth attach /var/lib/geth/geth.ipc

Now, you can check the sync status (it will work now!):

>eth.syncing

Press CTRL + D to exit.

Step 11 Import Validator Keys

To import the keys into Prysm, we’ll need to get them onto the same machine.

Copy Validator Keystore File(s) to Server

Before we transfer over the Validator Keystore file(s), we’ll need to create a place to store them:

sudo mkdir -p $HOME/staking-deposit-cli/validator_keys

Next, ensure your user has control of that folder:

sudo chown -R {yourusername}:{yourusername} $HOME/staking-deposit-cli/validator_keys

Now, plug the USB into your Node from Step 1 (remember Step 1?).

Back in terminal, check to see if the drive is recognized:

sudo fdisk -l

This will list all available disks and partitions. You should see the USB drive listed as a block device, such as /dev/sdb or /dev/sdc, and specific drives underneath. Look for your USB drive and note its code (e.g. sdb1 or sdc1).

Create a mount point for the USB drive by running the following command:

sudo mkdir /mnt/usb

Then, mount the USB drive to the mount point, replacing sdb1:

sudo mount /dev/{sdb1} /mnt/usb

Check that the USB drive is connected by looking at all mounted drives:

df -h

Now, it’s time to copy the files from the USB to the proper folders within the Node. First, let’s get a list of all files by running:

ls /mnt/usb

This should show something like the following

deposit_data-1682896118.json keystore-m_12381_3600_0_0_0-1682896115.json

Note that while you will only ever have 1 deposit file (regardless of the amount of validators), you will have 1 keystore file for each validator you are setting up on the Node. You only need to move the keystore file(s) to the validator_keys folder.

Now that we have the file names, we issue a command to copy those files from /mnt/usb to $HOME/staking-deposit-cli/validator_keys:

cp /mnt/usb/{keystore-filename.json} $HOME/staking-deposit-cli/validator_keys/

If you have more than 1 validator key, you will need to rerun the above command once for each. BE SURE TO ONLY HAVE 1 COPY OF EACH VALIDATOR KEY.

Before unmounting the USB, let’s verify that the files were placed into the folder correctly by running:

ls $HOME/staking-deposit-cli/validator_keys/

If you see 1 copy of each validator key you intended to move, you’re all set!

Now, unmount the USB:

sudo umount /mnt/usb

Import the Validator Keystore Files into Prysm

REMEMBER: If you import the same keystore twice OR run the same keystore on multiple nodes at the same time YOU WILL GET SLASHED!

Now we will run the validator import process. You will need to provide the directory where the generated keystore-[..].json files are located. E.g. $HOME/staking-deposit-cli/validator_keys (as determined above in this step)

sudo systemctl stop prysmvalidator
sudo /usr/local/bin/validator accounts import --keys-dir=$HOME/staking-deposit-cli/validator_keys --wallet-dir=/var/lib/prysm/validator --mainnet
sudo systemctl start prysmvalidator

You will then be presented with a terms of use which you will need to accept in order to continue.

Following your acceptance, you’ll be prompted to create a wallet password. Note that this is a different password than the validator password set in step 1 when generating the keystore files. This password will be used by Prysm to decrypt the validator files. Note this password on the variables document.

After setting your wallet password, you’ll be asked to enter the validator keystore password, this is the one referenced above and created during step 1. Once this password is entered, all validator keystore file(s) will be imported.

Create a Wallet Password File

Create a file to store the wallet password so the Prysm validator service (set up below) can access the wallet without you having to supply the password:

sudo nano /var/lib/prysm/validator/password.txt

This will create a new text file and open a nano text editor. Type your password you just created for your validator wallet into the the file.

Press CTRL + X then Y then ENTER to save and exit.

Let’s now check that Prysm can see the password:

sudo systemctl status prysmvalidator

Before continuing to the deposit step, let’s do one more permissions check:

sudo chown -R prysmvalidator:prysmvalidator /var/lib/prysm/validator && sudo chown -R {yourusername}:{yourusername} /var/lib/prysm/validator
sudo systemctl daemon-reload

Step 12 Fund the Validators

Now that the Consensus Client is up and running, to actually begin staking on the Ethereum network you will need to deposit ETH to fund your validators.

Note: DO NOT continue until your execution and consensus clients are fully synced. If they have not and your validator(s) become active on the network, you would be subject to inactivity penalties. You can determine sync status by checking the status of the Beacon Chain or through attaching the Geth console, both methods are described above.

With the deposit file in hand and an EOA with 32ETH per validator + some spare ETH for gas, head to the Ethereum Launchpad

Click on Become a Validator, click through the warning steps and continue through the screens until you get to the Generate Key Pairs section. Select the number of validators you are going to run. Choose a value that matches the number of validators you created in Step 1.

Scroll down, check the box if you agree, and click Continue.

You will be asked to upload the deposit_data-[timestamp].json file. You generated this file in Step 1. (Note: There are no security concerns copying the file or having access to it on a public computer). Double check that inside the file the withdrawal address is set correctly. When satisfied, browse or drag the file to upload and click continue.

Connect your wallet. Choose MetaMask (or one of the other supported wallets), log in, select the account where you have your ETH and click Continue.

Your MetaMask balance will be displayed. The site will allow you to continue only if you have selected Mainnet and you have a sufficient ETH balance.

A summary shows the number of validators and total amount of ETH required. Tick the boxes if you agree and click continue.

If you are ready to deposit click on Initiate All Transactions.

This will pop open MetaMask (or one of the other supported wallets) where you can confirm and broadcast each transaction.

Once all the transactions have successfully completed you are done! WOOOOOOO! Congratulations you have deposited your stake!

Check the Status of Your Validator Deposits

Newly added validators can take a while to activate. You can check the status of your keys with these steps:

Copy your wallet address used to make the deposit
Go to Beaconcha.in
Search for your key(s) using your wallet address

Digging into a specific validator we can see a Status section that provides an activation estimate time for each validator.

That’s it. You now have a functioning Execution and Consensus client and the staking deposit done. Once your deposit is active you will automatically begin staking and earning rewards.

Probably a good time to touch grass.

Addendum Adding Validators to Existing Config

This section provides guidance for adding additional valiadtors to your existing config. In addition to all information required in Step 1 Generate Staking Data, you will also need to know the validator_start_index, which is the number of validators you already have created using your mnemonic.

Clean Up `validator_keys`

While not essential as you can always regenerate them using your mnemonic, it’s good practive to back up the validator_keys directory (typically $HOME/staking-deposit-cli/validator_keys) on a USB for emergencies.

After ensuring you have a backup of these files as described in Step 1 Generate Staking Data, you can safely remove the validator_keys directory. Note that this will not impact your existing validators, as in Step 11 Import Validator Keys the validator_keys are imported into the validator instance. The copies referenced above are “extra”:

sudo rm -r $HOME/staking-deposit-cli/validator_keys

Generate Additional Staking Data

Best practice is to complete this step on an airgapped machine as described in Step 1 Generate Staking Data, as you will need to directly enter your mnemonic in order to generate the staking data.

Note: You must use the same keystore password as you used for the existing validators. This should be noted on the variables document you created during your first set up.

Please refer to Step 1 Generate Staking Data to get set up with an airgapped machine running Ubuntu Desktop. We’ll pick up again below starting with the deposit CLI commands.

Now, run the binary file in a terminal window on your Linux desktop by using the below command (easier if you have your withdrawal address handy for a copy/paste!)

sudo ./deposit existing-mnemonic --validator_start_index {#_Existing_Validators} --num_validators {#_New_Validators} --chain mainnet --eth1_withdrawal_address {YourWithdrawalAddress}

Replace {#_Existing_Validators} with the number of validators you have already generated with this mnemonic, and replace {#_New_Validators} with the number of additional validators you want to run (32ETH per), and {YourWithdrawalAddress} with an Ethereum address you control.

Note: If you plan to set up your validator and take advantage of restaking via EigenLayer, you will likely want to check this portion of the guide beofre completing this step.

Once you have confirmed your mnemonic your validator(s) will be created. The following files will be generated and placed on your desktop.

The deposit_data-[timestamp].json file contains the public key(s) for the validator(s) and information about the staking deposit. This file will be used to complete the ETH staking deposit process later in this guide. This is where you can triple check the withdrawal address
The keystore-[..].json files contain the encrypted validator signing key. There is one keystore file per validator that you are funding. These will be imported into the Consensus Client for use during validation operations.
If you lose or accidentally delete the files it is possible to regenerate them using the Staking Deposit CLI tool and your mnemonic via the existing-mnemonic command (see here).

Note: there are no other steps in this process that require you to enter or view your mnemonic phrase, so the air-gapped portion of this process is completed.

Armed with the requisite data, please see above and complete Step 11 Import Validator Keys and Step 12 Fund the Validators to complete spinning up your additional validator(s). Please ensure you make a backup of any additional validator_keys generated during this process. Remember that they can be regenerated as needed!

Validators

​Table of Contents

​Step 0 Purchase Equipment and Assemble NUC

​Step 1 Generate Staking Data

​Step 2 Install Linux Server

​Step 3 Secure the Server

​Modify the Default SSH Port

​Configure the Firewall

​Configure Fail2Ban

​Disable Root Access

​Step 4 Configure Port Forwarding

​Step 5 Configure Timekeeping

​Step 6 Generate Client Auth Secret

​Step 7 Install Geth

​Step 8 Install Prysm

​Step 9 Configure the Beacon Node Service

​Step 10 Configure the Validator Service

​Step 11 Import Validator Keys

​Copy Validator Keystore File(s) to Server

​Import the Validator Keystore Files into Prysm

​Create a Wallet Password File

​Step 12 Fund the Validators

​Check the Status of Your Validator Deposits

​Addendum Adding Validators to Existing Config

​Clean Up validator_keys

​Generate Additional Staking Data

Table of Contents

Step 0 Purchase Equipment and Assemble NUC

Step 1 Generate Staking Data

Step 2 Install Linux Server

Step 3 Secure the Server

Modify the Default SSH Port

Configure the Firewall

Configure Fail2Ban

Disable Root Access

Step 4 Configure Port Forwarding

Step 5 Configure Timekeeping

Step 6 Generate Client Auth Secret

Step 7 Install Geth

Step 8 Install Prysm

Step 9 Configure the Beacon Node Service

Step 10 Configure the Validator Service

Step 11 Import Validator Keys

Copy Validator Keystore File(s) to Server

Import the Validator Keystore Files into Prysm

Create a Wallet Password File

Step 12 Fund the Validators

Check the Status of Your Validator Deposits

Addendum Adding Validators to Existing Config

Clean Up `validator_keys`

Generate Additional Staking Data
